ACTi B76A 12MP Outdoor Hemispheric Dome Camera

pengenalan

This manual provides detailed instructions for the installation, operation, and maintenance of your ACTi B76A 12MP Video Analytics Outdoor Hemispheric Dome Camera. Please read this manual thoroughly before using the product to ensure proper setup and functionality. Keep this manual for future reference.

Produk Selesaiview

The ACTi B76A is a high-performance 12-megapixel hemispheric dome camera designed for outdoor surveillance. It features advanced video analytics, superior low light sensitivity, and robust environmental protection.

Komponen Kamera

Image: Diagram illustrating the key components and connection points of the ACTi B76A camera.

1. Slot Kad Memori: For local storage of video footage using MicroSDHC/MicroSDXC cards.
2. Input / Output Audio: Connect external audio devices for two-way communication.
3. Digital Input/Output: Interface for connecting external sensors or control devices.
4. Butang Tetapkan Semula: Used to restore the camera to factory default settings.
5. Pelabuhan Ethernet: RJ-45 connector for network connection and Power over Ethernet (PoE).
6. Input Kuasa DC 12V: Alternative power connection point.
7. Mikrofon terbina dalam: For audio capture.

Ciri-ciri Utama

• Resolusi Tinggi: 12MP image sensor for detailed surveillance.
• Superior Low Light Sensitivity (SLLS): Enhanced performance in challenging lighting conditions.
• Adaptive IR LED: Built-in infrared illumination for night vision up to 20 meters.
• Kanta Mata Ikan: f1.65mm/F2.8 lens providing 360°/180° panoramic views.
• Dewarped Streaming: Berbilang view modes including fisheye, dewarped, 270° corner, and ePTZ.
• Extreme WDR (130 dB): Wide Dynamic Range for clear images in high-contrast scenes.
• Analitis Video Lanjutan: Includes Object Based Motion Detection, Tampering Detection, Shock Detection, Digital Auto Tracking, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, and Object Loitering Detection.
• Peningkatan Imej: Features like White Balance, Brightness, Contrast, Sharpness, Automatic Gain Control, Flickerless, and Defogging.
• Audio Dua hala: Built-in microphone with audio input/output for interactive communication.
• Storan Setempat: MicroSDHC/MicroSDXC card slot for on-device recording.
• Kuasa Ethernet (PoE): Simplifies installation by providing power and data over a single cable.
• Reka Bentuk Teguh: IP68 weatherproof and IK10 vandal-proof casing for outdoor durability.
• Suhu Operasi Lebar: Functions reliably from -40°C to 50°C.

Persediaan

1. Membongkar dan Pemeriksaan

Carefully unpack the camera and all accessories. Inspect for any signs of damage. If any components are missing or damaged, contact your vendor immediately.

2. Memasang Kamera

The ACTi B76A is designed for outdoor wall or ceiling mount installations. Ensure the mounting surface is strong enough to support the camera's weight. Use appropriate screws and anchors for secure installation. Refer to the included mounting template for drilling holes.

3. Sambungan Kuasa

• Kuasa Ethernet (PoE): Connect an Ethernet cable from a PoE-enabled switch or injector to the camera's Ethernet port. This provides both power and network connectivity.
• Kuasa DC 12V: Alternatively, connect a DC 12V power adapter (not included) to the DC 12V power input port. Ensure the power supply meets the camera's specifications (7W minimum).

4. Sambungan Rangkaian

Connect an Ethernet cable from your network switch or router to the camera's Ethernet port. Ensure your network is configured to assign an IP address to the camera (DHCP recommended for initial setup).

5. Konfigurasi Awal

Once powered and connected to the network, use the ACTi IP Utility software (available on the ACTi website) to discover the camera on your network. Access the camera's web interface using its assigned IP address to perform initial setup, including setting a strong password, configuring network settings, and adjusting basic video parameters.

Beroperasi

1. Mengakses Siaran Langsung View

Buka a web browser and enter the camera's IP address. Log in with your credentials. The live view interface will display the camera's video feed. You can switch between different view modes (Fisheye, Dewarped, 270° Corner, Multiple, ePTZ) from the interface.

2. Configuring Video Settings

Navigate to the video settings section in the web interface to adjust resolution, frame rate, compression (H.264, MJPEG), and image quality parameters such as brightness, contrast, sharpness, and WDR settings.

3. Utilizing Video Analytics

The camera offers a suite of built-in video analytics. Access the analytics configuration section to enable and customize features like motion detection, line crossing, and object detection. Define detection zones and sensitivity levels as required for your surveillance needs.

4. Audio Functionality

Enable and configure the built-in microphone for audio monitoring. If external speakers are connected to the audio output, two-way audio communication can be established through the web interface or compatible VMS.

5. Rakaman dan Penyimpanan

Configure recording schedules and storage destinations. You can record directly to a MicroSDHC/MicroSDXC card inserted into the camera's memory card slot, or to a Network Video Recorder (NVR) or other network storage solutions.

6. Event Management

Set up event triggers based on video analytics, digital inputs, or sound detection. Configure event responses such as email notifications, push notifications to mobile devices, saving video to local storage, or activating external devices via digital outputs.

Penyelenggaraan

1. Membersihkan Kamera

Regularly clean the camera's dome cover and housing with a soft, damp cloth. Avoid using abrasive cleaners or solvents that could damage the surface or lens. Ensure the camera is powered off before cleaning.

2. Kemas Kini Perisian Tegar

Periodically check the ACTi website for the latest firmware updates. Keeping your camera's firmware up-to-date ensures optimal performance, security, and access to new features. Follow the provided instructions carefully when performing firmware updates.

3. Environmental Checks

For outdoor installations, periodically inspect the camera's mounting and cabling for any signs of wear, corrosion, or damage. Ensure all seals are intact to maintain the IP68 weatherproof rating.

Menyelesaikan masalah

Tiada Kuasa

• Verify that the PoE switch/injector is functioning correctly or that the DC 12V power adapter is properly connected and supplying power.
• Periksa semua sambungan kabel untuk memastikan ia dipasang dengan selamat.

Tiada Sambungan Rangkaian

• Ensure the Ethernet cable is securely connected to both the camera and the network device.
• Check network settings (IP address, subnet mask, gateway) using the ACTi IP Utility.
• Confirm that the network switch port is active and configured correctly.

Kualiti Imej Lemah

• Clean the camera's dome cover and lens.
• Adjust image settings (brightness, contrast, sharpness, WDR) in the web antara muka.
• Ensure sufficient lighting in the surveillance area, especially at night (check IR LED functionality).

Analytics Not Triggering

• Verify that the analytics features are enabled and correctly configured in the camera's web antara muka.
• Adjust detection zones and sensitivity levels to match environmental conditions.
• Pastikan tiada halangan yang menghalang kamera view in the detection areas.

Spesifikasi

Waranti dan Sokongan

For warranty information, please refer to the warranty card included with your product or visit the official ACTi website. Technical support and additional resources, including software downloads and FAQs, are available on the ACTi support portal. Please have your model number (B76A) and serial number ready when contacting support.
