ULTRAFIRE SK68

Manual Pengguna Lampu Suluh Mini LED ULTRAFIRE SK68

Model: SK68

1. Produk Lebihview

The ULTRAFIRE SK68 Mini LED Flashlight is a compact, durable, and ultra-bright tactical flashlight designed for everyday carry and various lighting needs. Featuring a single mode operation and an adjustable focus, it provides reliable illumination without complex settings. Its robust aluminum body ensures shock-resistance and water resistance, making it suitable for diverse environments.

Three ULTRAFIRE SK68 Mini LED Flashlights

Figure 1: Three ULTRAFIRE SK68 Mini LED Flashlights, showcasing their compact design and clip.

Various usage scenarios for the ULTRAFIRE SK68 flashlight

Gambar 2: Cthamples of the flashlight in use, including outdoor activities, cycling, and security applications.

2. Persediaan

2.1 Pemasangan Bateri

The ULTRAFIRE SK68 flashlight operates on either one (1) AA battery or one (1) 14500 3.7V rechargeable battery. Batteries are not included with the product.

  1. Tanggalkan penutup ekor lampu suluh dengan memusingkannya lawan arah jam.
  2. Insert one compatible battery (AA or 14500) into the battery compartment with the positive (+) end facing towards the flashlight head.
  3. Screw the tail cap back on clockwise until it is securely tightened. Ensure a tight seal for proper operation and water resistance.
Diagram showing two types of batteries compatible with the flashlight

Figure 3: Illustration of the two compatible battery types: 1x AA or 1x 14500 3.7V rechargeable battery.

3. Arahan Operasi

3.1 Hidupkan/Mati Kuasa

The ULTRAFIRE SK68 features a simple single-mode operation. To turn the flashlight on or off, firmly press the orange button located on the tail cap.

Hand pressing the tail cap button of the SK68 flashlight to turn it on/off

Figure 4: A hand demonstrating the simple on/off operation by pressing the tail cap button.

3.2 Adjusting Focus (Zoom Function)

The flashlight features a stepless zoom function, allowing you to adjust the beam from a wide floodlight to a concentrated spotlight.

  • To zoom in (narrow the beam for a spotlight), gently push the head of the flashlight forward.
  • To zoom out (widen the beam for a floodlight), gently pull the head of the flashlight backward.
Diagram illustrating the stepless zoom function of the flashlight

Figure 5: Visual representation of the stepless zoom feature, showing both zoom-in (spotlight) and zoom-out (floodlight) capabilities.

Examples of flashlight beam patterns at different zoom levels

Figure 6: Various beam patterns demonstrating the effect of the zoom function in different environments.

Hand holding a small LED flashlight with a beam extending 100 meters

Figure 7: The flashlight's maximum output of 300 lumens and a maximum beam distance of 100 meters.

4. Penyelenggaraan

4.1 Penjagaan Am

  • Pastikan lampu suluh bersih dan kering. Lap dengan kain lembutamp kain mengikut keperluan.
  • Avoid dropping the flashlight from excessive heights, although it is designed to be shock-resistant.
  • If not in use for an extended period, remove the battery to prevent leakage and damage to the flashlight.

4.2 Tahan Air

The ULTRAFIRE SK68 flashlight is IP65-rated water resistant, meaning it is protected from low-pressure water jets from any direction. It is suitable for use in heavy rain but is not designed for submersion in water.

ULTRAFIRE SK68 flashlight being used in the rain, highlighting its water resistance

Figure 8: The flashlight demonstrating its IP65 water resistance, suitable for use in wet conditions.

5. Penyelesaian masalah

  • Lampu suluh tidak menyala:
    Ensure the battery is inserted correctly with the positive (+) end facing the head. Check if the battery has sufficient charge. Tighten the tail cap completely.
  • Cahaya malap atau berkelip-kelip:
    Replace the battery with a fresh one or recharge the 14500 battery. Ensure the battery contacts are clean and free of debris.
  • Fungsi zum adalah kaku:
    Clean the sliding mechanism of the flashlight head. A small amount of silicone grease can be applied to the O-rings if necessary, but avoid petroleum-based lubricants.

6. Spesifikasi

Detailed specifications and dimensions of the ULTRAFIRE SK68 flashlight

Figure 9: Visual representation of the flashlight's dimensions and key specifications.

CiriSpesifikasi
JenamaULTRAFIRE
ModelSK68
Jenis Sumber CahayaLED
Kecerahan300 Lumen (Output Maksimum)
Jarak PancaranUp to 100 Meters (50 Meters specified in specs, 100M in image)
ModSingle Mode (On/Off)
Fungsi ZumStepless Zoom (Spotlight to Floodlight)
Sumber Kuasa1x AA Battery or 1x 14500 3.7V Rechargeable Battery (Not Included)
bahanAloi Aluminium
Tahan AirIP65 Rated (Water Resistant)
Rintangan Kejutanya
Dimensi (L x W x H)lebih kurang 3.89" x 1.03" x 1.03"
Berat badanApprox. 0.44 lbs (7 ounces)
Masa jalan100,000 hours (LED lifespan)

7. Waranti dan Sokongan

The ULTRAFIRE SK68 Mini LED Flashlight comes with a seller warranty. For any support inquiries, warranty claims, or further assistance, please contact the seller directly through your purchase platform.

For more information about ULTRAFIRE products, you may visit the official ULTRAFIRE Store: ULTRAFIRE Store on Amazon.

© 2024 ULTRAFIRE. Hak cipta terpelihara.
