ProfiCare PC-PW 3008 BT 9-in-1 Diagnostic Scale User Manual

1. Pengenalan

The ProfiCare PC-PW 3008 BT is a sophisticated 9-in-1 diagnostic scale designed to provide comprehensive insights into your body composition. Utilizing modern Bluetooth Smart technology, this scale measures not only your weight but also calculates body fat percentage, water content, muscle mass, bone mass, organ fat, calorie needs, Body Mass Index (BMI), and biological age. All data is transmitted directly to a dedicated smartphone application for continuous tracking and evaluation.

Image 1.1: ProfiCare PC-PW 3008 BT Diagnostic Scale with key features such as easy-to-read display, 180kg measurement range, step-on function, 10-user memory, low battery indicator, and Bluetooth smart technology.

2. Maklumat Keselamatan

• Peranti ini bertujuan untuk kegunaan peribadi sahaja dan bukan untuk diagnosis atau rawatan perubatan.
• Jangan gunakan peranti ini jika anda mempunyai perentak jantung atau peranti perubatan dalaman yang lain.
• Jauhkan penimbang daripada air dan suhu yang melampau.
• Permukaan skala boleh licin apabila basah. Melangkah dan turun dengan berhati-hati.
• Jangan melompat pada skala.
• Jauhkan daripada kanak-kanak.
• Buang bateri mengikut peraturan tempatan.

3. Kandungan Pakej

Sila pastikan semua item ada dan dalam keadaan baik:

• ProfiCare PC-PW 3008 BT Diagnostic Scale
• Manual Pengguna

Note: 3 x 1.5V AAA batteries are not included and must be purchased separately.

4. Persediaan

4.1 Pemasangan Bateri

1. Balikkan penimbang untuk mengakses petak bateri di bahagian bawah.
2. Buka penutup petak bateri.
3. Masukkan tiga (3) bateri AAA 1.5V, pastikan kekutuban (+/-) yang betul.
4. Tutup penutup petak bateri dengan selamat.

4.2 Pemasangan Aplikasi

1. Cari untuk the official ProfiCare app on your smartphone's app store (e.g., Apple App Store or Google Play Store).
2. Download and install the free application.
3. Follow the on-screen instructions to create a user profile dalam apl.

4.3 Berpasangan Bluetooth

1. Pastikan Bluetooth didayakan pada telefon pintar atau tablet anda.
2. Open the ProfiCare app.
3. Langkah ke atas penimbang untuk mengaktifkannya. Paparan akan menyala.
4. The app should automatically detect and connect to the scale. If not, follow the pairing instructions provided within the app.

5. Arahan Operasi

5.1 Mengambil Pengukuran

1. Letakkan penimbang di atas permukaan yang keras dan rata. Elakkan permaidani atau lantai yang tidak rata.
2. Pastikan kaki anda bersih dan kering.
3. Step onto the scale barefoot. Stand still with your weight evenly distributed.
4. The scale will automatically turn on (Step-On function) and display your weight.
5. After a few seconds, the scale will perform the full diagnostic analysis.
6. Your measurements will be displayed on the LCD and automatically transmitted to the ProfiCare app via Bluetooth.

5.2 Unit Pengukuran Pensuisan

The scale supports measurement in kilograms (kg), pounds (lb), and stone:pounds (st:lb). To switch units, locate the unit switch button on the underside of the scale (usually near the battery compartment) and press it to cycle through the available units.

5.3 Pengguna Profiles

The scale can store data for up to 10 different users. User profiles are managed through the ProfiCare app. Ensure you select the correct user profile in the app before taking a measurement to ensure data is assigned accurately.

Imej 5.1: Jarak dekat view of the ProfiCare PC-PW 3008 BT scale, showing the stainless steel surface, LCD display, and touch controls for navigation.

6. Data Interpretation

The ProfiCare app provides detailed explanations and historical data for each measurement. Consult the app for personalized insights and trends.

• Berat: Your total body mass.
• Peratus Lemak Badantage: Nisbah lemak kepada jumlah berat badan.
• Kandungan air: Peratusantage air dalam badan anda.
• Jisim otot: Jumlah berat otot dalam badan anda.
• Jisim Tulang: Jumlah berat tulang dalam badan anda.
• Organ Fat (Visceral Fat): Fat stored around the organs in the abdominal cavity.
• Calorie Needs (BMR/TDEE): An estimate of the calories your body needs daily.
• BMI (Indeks Jisim Badan): Ukuran lemak badan berdasarkan ketinggian dan berat badan.
• Biological Age: An estimate of your body's physiological age compared to your chronological age.

7. Penyelenggaraan dan Penjagaan

• Bersihkan permukaan kerak dengan kain lembut,amp kain. Jangan gunakan pembersih yang kasar atau rendam kerak di dalam air.
• The stainless steel surface is designed to be hygienic and easy to clean.
• Jika penimbang tidak akan digunakan untuk tempoh yang lama, tanggalkan bateri untuk mengelakkan kebocoran.
• Simpan skala di tempat yang sejuk dan kering.
• The scale features an automatic shut-off function to conserve battery life. A low battery indicator will appear on the display when batteries need replacement.

8. Penyelesaian masalah

9. Spesifikasi

• model: PC-PW 3008 BT
• Nombor Model: 330080
• EAN/UPC: 04006160300802
• Julat Pengukuran: 5 kg hingga 180 kg (11 lb hingga 396 lb)
• Kenaikan Pengukuran: 100 g (0.2 lb)
• Unit Pengukuran: kg, lb, st:lb (switchable)
• paparan: High-quality multifunction LCD (black/white)
• Memori Pengguna: Sehingga 10 pengguna berbeza
• Bekalan Kuasa: Bateri AAA 3 x 1.5V (tidak termasuk)
• Bahan Permukaan: Extra-large, high-quality stainless steel (approx. 30 x 30 cm)
• ciri-ciri: Modern touch control, automatic Step-On function, anti-slip feet, automatic shut-off, low battery indicator.
• Berat produk: 1.7 kg
• Negara Asal: China

Image 9.1: The ProfiCare PC-PW 3008 BT scale being held, showcasinreka bentuknya yang anggun dan faktor bentuknya yang padat.

10. Waranti dan Sokongan

This product comes with a 1-year availability for spare parts. For warranty claims, technical support, or further assistance, please contact ProfiCare customer service. Refer to the official ProfiCare webtapak atau dokumentasi pembelian anda untuk butiran hubungan.
